Portable operating Room light LED shadowless operating lamp

Portable operating Room light LED shadowless operating lamp

WITH SQUARE ARM

MODEL: 500D

• Utilizing the most advanced LED technology available.
• The MT-medical LED70 series of operating theatre lights have been designed to provide a high quality, shadowless beam with extremely low running costs.
• The new, slim, fully enclosed head with colour touchscreen digital controls is a perfect LED lighting solution complementing all surgical room.
• LEDs (light emitting diodes) have been around for a long time. Recently this technology has become leading-edge in the field of lighting – a breakthrough technological solution to the inherent problems of the incandescent light bulb.
• We have taken the technology and developed it further to provide high definition lighting solutions with no infrared, low environmental impact, high brightness, low power consumption, no toxic chemicals and a long operating life

• Streamlined, ultra-thin, enclosed head with reduced air resistance to minimise contamination

• Automatic focus (Optional Electrical or Manual focus system) Warm and Cold light source (Osram LED bulbs)

• Germany Ondal Light arm with 360°rotation LCD tourch screen pannel or optional manual control panel

• Optional Sony camera system,There are insterted camera in central of light head and fixed in third light arm for choice

• Aluminium alloy cover : easily heat dissipation

• Technical Parameters: 700mm head and 500mm head
• Illuminance: 160000/140000Lux.
• Color temperature: 3500K-5500K (± 500)
• Ultraviolet light irradiance within40nm wave: 0.002W/M2
• Light Focus adjustment System: manual or electric or auto focus (Optional)
• Light-adjusting mode: continuous adjusting light , no grade dimmer system
• 50% Spot Diameter (D50): 280 mm / 230 mm
• 50% Spot Diameter (D50): 150mm/120mm
• Terperature at surgeon’s head: ≤ 2°C
• CRI RA: 95 R9 :90 R13 :92
• Input Power: 85W / 65W
• the adjusting range of Illumination%: 25~100
• Input power: 220W
• Power of bulb (W): 1W * 60N / 1W *45N
• Bulb average life: 50000h
