AUTOCLAVE SA-260MA – 24 LITRE

AUTOCLAVE SA-260MA – 24 LITRE

• Microprocessor control system: Fully automatic control from Pre-vacuum to dry and 24 programs for your selection
• Pre-heating by dry heater ensuring chamber temperature balance and perfect drying function
• Special LIQUID sterilization program: it is the special function for laboratory and scientific use
• Special PRION sterilization program: it is the special program for PRION sterilization
• Special BOWIE-DICK test program: the users can identify the perfect sterilization function with this program
• An “ERROR” indicator, to help the users and engineers to find the function problem automatically

SPECIFICATIONS:

• MODEL :: SA-260MA (B-CLASS)
• Overall Dimensions: 655mm x 533mm x 442mm
• Chamber Dimension: 260mm x 450mm
• Capacity: 24 l
• Temperature / Pressure: Unwrapped / Wrapped : 121 – 134°C ; 2.2kg per cm²
• Liquid : 121°C ; 1.2kg per cm²
• Control System: Pressure control
• Power Consumption: 220 V: 1.8kW ; 8.3Amp / 240 V: 2.1kW ; 8.8Amp
• Auto-fill Water System: Yes
• Double Water Level Check Device: Yes : One for water tank ; one for chamber water level check
• Auto Drying: Yes : 0, 15, 30, 35 or 40 minutes
• Pre-Vacuum: Yes
• Dry-Vacuum: Yes
• Indicators / Temperature Display: Yes / LED
• Sterilization Temp / Time: Wrapped : 121°C – 30 min; 134°C – 15 min
• Unwrapped: 121°C – 15 min; 134°C – 4 min
• Standard Accessories: Sterilization box x 1 ; Tray x 1
• Optional Accessories: Tray frame x 1 ; Tray holder x 1 ; Tray x 3 ; Spring x 2
• Safety Devices: ü Temperature control switch
• ü Pressure door auto-lock device
• ü Emergency key – cuts power supply & exhausts chamber pressure
• ü Chamber pressure gauge + pressure & steam pressure safety valve
• ü Door close indication
• ü Low water alarm and indication
• ü Over-heat protector
• ü Safety valve
• ü Electronic circuit safety system
• ü Low water indicator & shutout device
• ü Sterilization completion indicator
• Quality Standard: CE-MDD
